Product Description:
Shipbuilding Plates Specifications
Our company can provide shipbuilding plates in a range of specifications to meet the needs of customers worldwide. Our inventory includes:
1. Hot Rolled Medium Steel Shipbuilding Plate
We are capable of supplying medium steel shipbuilding plates that meet the Quality Authentication standards of various Classification Societies, including LR, ABS, NK, GL, DNV, BV, KR, RINA, and CCS.
2. Hot Rolled High Strength Shipbuilding Plate
Our company also offers high strength shipbuilding plates that are specifically designed for use in the construction of sea vessels. These plates are available in the following grades: AH32, AH36, DH32, DH36, EH32, EH36, AH40, and DH40 with a thickness ranging from 3-200mm, a width of 1500-4000mm and a length of 5000-18000mm.
No matter your specific needs, our inventory has the variety and quality to fulfill your shipbuilding plate requirements. Contact us today to learn more about our product offerings.
Technical data
Chemical Composition and Mechanical Property:
| Grade | Chemical Composition(%) |
| C | Mn | Si | P | S | Al | Cu | Mark |
| ABS AH36 | 0.18 | 0.90-1.60 | 0.10-0.50 | 0.035 | 0.035 | 0.015 | 0.35 | AB/AH36 |
| ABS DH36 | AB/DH36 |
| ABS EH36 | AB/EH36 |
| ABS FH36 | 0.16 | 0.025 | 0.025 | AB/FH36 |
| Grade | Mechanical Property |
| Tensile Strength(MPa) | Yield Strength(MPa) | % Elongation in 2 in.(50mm) min | Impacting Test Temperature(°C) |
| ABS AH36 | 490-620 | 355 | 21 | 0 |
| ABS DH36 | -20 |
| ABS EH36 | -40 |
| ABS FH36 | -60 |
Features:
There are several categories of shipbuilding materials available, with variations in thickness, width, and length/inner diameter. One such category is shipbuilding plate, which is available in cutting and non-cutting edges. The thickness of the plate can range from 6mm to 50mm, while the width can vary from 1500mm to 3000mm. The length of the plate depends on whether it has cutting edges or non-cutting edges, with cutting edges having a length range of 3000mm to 15000mm and non-cutting edges ranging from 1300mm to 3000mm.
Another category of shipbuilding material is shipbuilding coil, which also comes in cutting and non-cutting edges. The thickness of the coil can range from 6mm to 20mm, while the width can vary from 1500mm to 2000mm. The length of the coil with cutting edges can range from 760+20mm to 760-70mm, while the length of the non-cutting edges coil is between 1510mm and 2010mm.
Technical Parameters:
Steel Grades and Requirements
There are several different grades of steel that are used for various purposes in construction and other industries. Each grade has specific requirements for its chemical composition in order to meet certain performance standards.
Grade A
This grade of steel requires a maximum carbon content of 0.22%, and the manganese content must be greater than or equal to 2.5 times the carbon content. The silicon content must be between 0.10% and 0.35%, and the maximum phosphorous content is 0.04%. The maximum sulfur content is 0.40%, and there is no requirement for aluminum, niobium, or vanadium content.
Grade B
Grade B steel has a maximum carbon content of 0.21%, and the manganese content must be between 0.60% and 1.00%. The silicon content is the same as in Grade A (between 0.10% and 0.35%), and the maximum phosphorous content is 0.04%. The maximum sulfur content is 0.40%, and there is no requirement for aluminum, niobium, or vanadium content.
Grade D and E
Both Grade D and E steels have a maximum carbon content of 0.21%, and the manganese content must be between 0.60% and 1.00%. The silicon content is also between 0.10% and 0.35%, and the maximum phosphorous content is 0.04%. The main difference between Grade D and E is in the maximum sulfur content; for Grade D it is 0.04%, while for Grade E it is 0.04% but with a minimum aluminum content of 0.015%.
Grade A32, D32, E32 and A36, D36, E36
These grades of steel have a maximum carbon content of 0.18%, and the manganese content must be between 0.70% and 1.60%. They also have varying levels of silicon, phosphorous, and sulfur content. The main difference between A32/D32/E32 and A36/D36/E36 is in the vanadium content; A36/D36/E36 require a minimum vanadium content of 0.015%, as well as a range of aluminum and niobium content.
Applications:
Shipbuilding steel plate is a type of steel plate specifically designed for use in Shipbuilding and Ocean Offshore Structural Projects. The steel plate is processed through various techniques to ensure that it meets specific requirements such as high strength, durability, and resistance to corrosion and impact.
In Shipbuilding Projects, the steel plate is used to construct various components of the ship such as the hull, deck, and bulkheads. The use of this specialized steel plate ensures that the ship is strong enough to withstand the harsh conditions of the ocean and is able to safely transport cargo and passengers.
In Ocean Offshore Structural Projects, the steel plate is used to construct offshore oil rigs, platforms, and other structures. These structures are subjected to strong ocean currents and harsh weather conditions and require a high level of strength and durability to ensure safe operation and longevity of the structure.
In summary, Shipbuilding steel plate is an essential component in the construction of ships and offshore structures. The use of this specialized steel plate ensures that these structures are capable of withstanding the harsh conditions of the ocean and are able to safely transport goods and people or operate offshore.
Packing and Shipping:
The shipbuilding steel plates are packed in wooden pallets or bundles with plastic wrapping for protection during transportation.
Shipping:
The shipbuilding steel plates will be shipped via sea freight. The delivery time may vary depending on the destination and shipping method chosen by the customer.
